Our newest Batteries incorporate Lithium Ion Phosphate Technology for maximum performance, faster recharging, and Multiple levels of safety features.
Sonnen LI battery System can be added to any Grid Tie System as a standalone Power generation Module. With powerful Sony Batteries, Outback Radion Inverter Technology and Maximum power production. The system is enclosed in a Nema Rated Enclosure and features a full range of Load Management Features that can be set from a cell phone or Lap top computer. Coupled with Grid Interface Solar Systems, this couples Emergency power management with Maximum Sell back Efficiencies. https://www.sonnen-batterie.com/
Lithionics Lithium Iron Phosphate batteries are rigorously tested and Feature an internal Battery Management Interface with light weight manageability. This is the newest reliable technology in sealed batteries to run larger loads during a Grid interruption. Featuring the NeverDie® Battery Management System (BMS), this is a True innovative technology for reliable power storage.
Patented electronics customize your battery during manufacturing. The NeverDie® Battery Management System (BMS) is always active, monitoring battery vitals. Within the Battery Management System (BMS), this provides protection against over charging and over discharging, accidental short circuit, cell balancing, temperature extremes, the option for remote telemetry, and the option for state-of-charge (SOC) monitoring. The NeverDie® Battery Management System (BMS) feature is available on most models. In some cases, the NeverDie® Battery Management System (BMS) is connected as an external component.
Click the links below for additional information to view or print…
Lithium Ion Phosphate Technology
Lithionics Battery Installation
Superior Blueprinted Batteries
TRUTH and “BABY TRUTH” are the names given to our Superior Blueprinted Batteries, incorporating 25 years of research and photovoltaic experience by Al Simpler. These Batteries are Custom Designed and manufactured exclusively for Simpler Solar Systems.
These batteries are designed for 1800 cycles @ 80% depth of discharge, after which the batteries remain within 80% of their original capacity! Compared to other “top quality” batteries which list ratings of 3800 cycles @ 10%, and 450 cycles @ 75%; the REALITY is that Simpler Solar Systems batteries outlast and outperform others by as much as 400%.
With over 10,000 batteries operating in PV applications designed by Simpler Solar Systems, there have been ZERO warranty claims.
Both Baby Truth and Truth Batteries incorporate our Unique Blueprinted Design Specifications for Long life & Low Maintenance. These Batteries typically last 20+ Years and use non arcing, non-corrosive elements to maintain their integrity and protect the Environment.
TECHNICAL DESIGN DATA – “TRUTH” – 29KWH Battery (2347 AH @ 100 hrs.)
- Description – 6 cell, 138 Amp plates, 23 plates each
- Battery Voltage – 12 Volts
- Number of Plates per Battery – 138 Plates
- # of Plates per Cell – 23 Plates
- Steel Trays – Acid Resistant Yellow Enamel
- KWH @ 100 Hrs. – 29
- Cover Material – Polypropylene w/ Floating Post.
- Discharge Test @ 100 Hrs. – 2347
- Case Material – Polypropylene
- Discharge Test @ 20 Hrs. – 1428
- Case to Cover Sealing Method – Heat Seal
- 6 Hour Test – 1210 AH
- Dimensions – 28″h x 12 3/4″d x 26 7/8″w
- Weight – 1118 lbs. Price: $3976+SH
Special Features Include: Extended jars to allow adequate breathing for hydrocaps, additional liquid reservoir, sealed jar tops, reversible hinged lid and extended 10 gauge steel case elongated to compensate for hydrocaps. Vent Type – Hydrovent. INCLUDES: Set of 5′ length cables, 350 Amp quick disconnect plugs, additional connector plug, welded interconnects with cone connectors (Ambassador Connector), and 2/0 cable.
TECHNICAL DESIGN DATA – BABY TRUTH – 10kWh Battery (747 AH @ 100hrs.)
- Description – 6 cell, 55 Amp plates, 15 plates each
- Battery Voltage -12 Volts
- Number of Plates per Battery – 90 Plates
- # of Plates per Cell – 15 Plates
- Steel Trays – Acid Resistant Yellow Enamel
- KWH @ 100 Hrs. – 9.72
- Cover Material – Polypropylene w/ Floating Post
- Discharge Test @ 100 Hrs. – 747
- Case Material – Polypropylene
- Discharge Test @ 20 Hrs. – 454
- Case to Cover Sealing Method
- Heat Seal 6 Hour Test – 385 AH
- Dimensions – 22 5/8 x 33 1/8 x 7 5/8
- Weight – 444 lbs
- Price: $2214 +SH
Battery Add-On Options
We also have smaller battery add on options to our most popular Photovoltaic Systems. These optional battery systems are designed to run specific circuits during outages. Typical circuits may include Refrigeration, Well Pump, lights and other vital equipment.
